Pichau Chronos B550M-CR Motherboard, DDR4, AMD AM4 Socket, M-ATX, AMD B550 Chipset
Motherboard | SATA Cable | Rear I/O Shield | M.2 Screw | User Manual
| Brand: | Pichau |
|---|---|
| Model: | PCH-B550M-CR |
| Chipset: | B550 |
| CPU: | Compatible with AMD Ryzen 3000 / 4000 / 5000 Series Processors (AM4 Socket) |
| Memory: | 4x DDR4 DIMM Slots (up to 3200 MHz with XMP Support) Dual Channel Support and up to 64 GB Total Capacity |
| Storage: | 2x M.2 Slots CN2 Slot: Supports NVMe PCIe 4.0 x4 and SATA 3.0 SSDs (Automatic Switching) CN3 Slot: Supports NVMe PCIe 3.0 x4 SSDs 4x SATA 6Gb/s Ports |
| Video Outputs: | 1x HDMI 2.0 1x DisplayPort |
| Network: | 1x RJ45 (Gigabit) Realtek Gigabit Chip + 1x Wi-Fi Interface (PCIe Protocol Support) |
| PCIe Slots: | 1x PCIe 4.0 x16 2x PCIe x1 |
| Audio: | 1x Audio Output (Line Out) 1x Microphone Input (MIC In) 1x Line Input (Line In) 1x F_Audio Connector for Front Panel |
| USB: | Rear I/O: 4 x USB 3.0, 4 x USB 2.0 Internal Header: 1 USB 2.0 Type-E Header (2 Additional USB 2.0 Ports) 1 USB 3.0 Header (Expandable to 2 USB 3.0 Ports) |
| Internal Connectors: | 1 x Front Panel Connector (FPANEL) 1 x Buzzer Connector (4-pin) 1 x CPU Fan Connector (4-pin – CPU Fan) 1 x System Fan Connector (4-pin – SYS Fan) 1 x System Fan Connector (3-pin – SYS Fan) |
| Power: | 24-pin ATX Connector + 8-pin Connector |
| Dimensions: | M-ATX Form Factor, 245 x 245 mm, 6 Layers (6L) |
Pichau Chronos B550M-CR Motherboard
Every second counts, and the Pichau Chronos B550M-CR understands that perfectly! Inspired by Chronos, the god of time, it puts performance first, delivering stability, power, and expansion possibilities to keep up with your pace. Compatible with AMD Ryzen 3000 to 5000 Series processors, this motherboard is the ideal foundation for a powerful, reliable, and future-ready system.
FORM FACTOR
Compact in size, but massive in power! With its M-ATX form factor, the Pichau Chronos B550M-CR delivers versatility and outstanding performance, featuring two M.2 slots for high-speed SSDs and four DDR4 slots for expandable memory. Perfect for versatile setups and ready to support your upgrades over time.
PERFORMANCE
Take your performance to the next level with the Pichau Chronos B550M-CR! Compatible with AMD Ryzen 3000 to 5000 Series processors, it supports up to 64 GB of DDR4 memory at 3200 MHz, delivering a smooth and responsive experience. Featuring two M.2 NVMe PCIe slots, including PCIe 4.0 support, it provides ultra-fast storage for running games and demanding applications with virtually limitless performance.
CONNECTIVITY
Connect, play, and expand your horizons without wasting time! The Pichau Chronos B550M-CR features USB 3.0 and 2.0 ports, Gigabit Ethernet networking, and Realtek HD Audio, ensuring speed, stability, and total immersion in your games. With HDMI 2.0 and DisplayPort outputs, you can power multiple monitors with dynamic visuals. Thanks to its PCIe slots, you'll also have broad compatibility for future hardware expansions.
Chipset
B550
Memory Support
4 DDR4 DIMM Slots (up to 3200 MHz with XMP Support)
Up to 64GB Memory Capacity
Supports DDR4 3200 Memory
Expansion Slots
1x PCIe x16 Slot
2x PCIe x1 Slots
Storage
4 SATA 3.0 Ports
2 M.2 2280 / 2260 / 2242 Slots
(Compatible with NVMe and NGFF Modes)
Audio
1x Audio Output (Line Out)
1x Microphone Input (MIC In)
1x Line Input (Line In)
1x F_Audio Connector for Front Panel
LAN
Realtek Gigabit Chip + 1x
Wi-Fi Interface (PCIe Protocol Support)
